切菜机工作原理以及操作事项

来源:https://www.sfxjxbj.com/ 浏览量: 时间:2022-05-13 14:51:05

切菜机是根据市场上切割传送带的切刀改进而来的,能够消除切割传送带对产品的污染。大型切菜机工作原理以及操作事项是怎样的呢?下面来了解一下吧。
The vegetable cutter is improved according to the cutter of cutting conveyor belt in the market, which can eliminate the pollution of cutting conveyor belt to products. What is the working principle and operation of large vegetable chopper? Let's take a look.
切割后的产品会自由落入收集器中,消除了圆盘式和滚刀式切菜机的二次离心力粉碎现象。尺寸准确,适用于白菜、卷心菜、韭菜、芥菜、蒜苗、海带、豆制品等茎、梗、叶类蔬菜的切、切丝、切片,是蔬菜加工、酸洗行业、大型超市、食堂、宾馆等切菜的理想机器。
The cut products will fall into the collector freely, which eliminates the secondary centrifugal force crushing phenomenon of disc and hob vegetable cutters. It is suitable for cutting, shredding and slicing stem, stem and leaf vegetables such as cabbage, cabbage, leek, mustard, garlic seedling, kelp and bean products. It is an ideal machine for vegetable processing, pickling industry, large supermarkets, canteens and hotels.
切菜机工作原理:物料在进料槽的输送带上向前行进,经上压带夹紧压紧后,送至上下往复运动的立刀切段。然后将材料切成正方形或长方形。
Working principle of the vegetable cutter: the material moves forward on the conveyor belt of the feed chute, and is clamped and compressed by the upper pressure belt, and then sent to the vertical knife cutting section with reciprocating motion from top to bottom. Then cut the material into squares or rectangles.
切菜机的型号很多,不同的型号、不同的厂家、不同的时期,设备价格会有很大差异,因此很难在市场上直接获得准确的报价。如上所述,山东给出的多功能大型切菜机价格合理,具体的切菜机市场报价,可以联系所购买设备的厂家来说明产量、等级要求等,得到合理的推荐和报价。
There are many models of vegetable chopper. The price of equipment will vary greatly with different models, manufacturers and periods, so it is difficult to obtain accurate quotation directly in the market. As mentioned above, the price of the multifunctional large-scale vegetable cutter given by Shandong is reasonable. For the specific market quotation of the vegetable cutter, you can contact the manufacturer of the purchased equipment to explain the output, grade requirements, etc., and get a reasonable recommendation and quotation.
大型切菜机
切菜机的操作:机器连续工作前,必须先进行试切,观察要切的蔬菜规格是否与要求的规格一致,否则应调整蔬菜的长度。满足要求后才能正常工作。安装立刀。打开防护罩,先转动可调偏心轮,使刀架运动到下死点,然后将刀架抬高1/2mm,拧紧立刀与刀架连接的螺母。
Operation of vegetable chopper: before the machine works continuously, trial cutting must be carried out first to observe whether the specification of vegetables to be cut is consistent with the required specification, otherwise the length of vegetables should be adjusted. It can work normally only after meeting the requirements. Install the vertical knife. Open the protective cover, first rotate the adjustable eccentric to move the tool holder to the bottom dead center, then raise the tool holder by 1 / 2mm, and tighten the nut connecting the vertical knife and the tool holder.
安装下刀刃。出厂时下刀刃与上刀配套。注意下刀刃必须与下刀刃中心对齐。切割长度的调整:观察试切割的长度值是否与要求的长度一致,调整偏心块的偏差距离,改变切割产品的长度。转动可调偏心轮,松开连杆紧固螺钉,移动滑块,由外向内,减少切割长度;移动滑块,由内向外,增加切割长度,调整后拧紧调整螺丝。
Install the lower blade. When leaving the factory, the lower blade is matched with the upper blade. Note that the lower blade must be aligned with the center of the lower blade. Adjustment of cutting length: observe whether the length value of trial cutting is consistent with the required length, adjust the deviation distance of eccentric block and change the length of cutting products. Turn the adjustable eccentric, loosen the fastening screw of the connecting rod, move the slider from outside to inside, and reduce the cutting length; Move the slider from inside to outside, increase the cutting length, and tighten the adjusting screw after adjustment.
大型切菜机的保养:切菜机操作前应置于水平地面上,确保机器放置平稳,机插头接触良好,无松动、无水痕。检查转筒内或传送带上是否有异物。如果有异物,必须清理干净,以免损坏工具。根据要加工的蔬菜选择加工方式。离心切片机用于切瓜、土豆等硬质蔬菜。立刀部分可加工叶类软质蔬菜或切片成不同规格的块状。丁字形、菱形等形状。
Maintenance of large vegetable cutting machine: before operation, the vegetable cutting machine should be placed on the horizontal ground to ensure that the machine is placed stably, the machine plug is in good contact, and there is no looseness or water mark. Check whether there are foreign matters in the drum or on the conveyor belt. If there is any foreign matter, it must be cleaned to avoid damaging the tool. Select the processing method according to the vegetables to be processed. Centrifugal slicer is used to cut hard vegetables such as melons and potatoes. The vertical knife part can process leaf soft vegetables or slice them into blocks of different specifications. T-shape, diamond shape, etc.
安装立刀并先转动,调整偏心轮使刀架到达下死点,然后将刀架抬高1-2mm,使立刀与输送机接触皮带,然后拧紧螺母并拧紧立刀。它固定在刀架上。如果刀架的高度很小,蔬菜可能会连接到刀上。如果刀架高度过大,可能会切断传送带。
Install and rotate the vertical knife first, adjust the eccentric wheel to make the knife rest reach the bottom dead center, then raise the knife rest by 1-2mm to make the vertical knife contact with the conveyor belt, and then tighten the nut and tighten the vertical knife. It is fixed on the tool holder. If the height of the knife holder is small, the vegetables may be connected to the knife. If the tool holder height is too high, the conveyor belt may be cut off.
大型切菜机工作原理以及操作事项经过以上的讲解,大家应该有所了解了,当然在使用之前要知道做好检查以及保养工作,更多内容就来网站www.sfxjxbj.com进行咨询吧。
After the above explanation, you should understand the working principle and operation of the large vegetable chopper. Of course, you should know to check and maintain it before use. For more information, please visit www.sfxjxbj.com Com.
